Pretech SBC RK3566: Versatile Single Board Computer

Model:E66
The Pretech SBC RK3566 is a powerful single-board computer powered by a quad-core Cortex-A55 processor and a 0.8 TOPS NPU for lightweight AI. It supports 4K@60fps video decoding and dual-screen displays via interfaces like HDMI, eDP, and LVDS. With versatile connectivity including Gigabit Ethernet, Wi-Fi 6, BT 5.2, and multiple USB ports, it is ideal for digital signage, interactive kiosks, and industrial automation. The board also offers extensive I/O like UART, I2C, and GPIO, supporting flexible secondary development for a wide range of embedded applications.
Inquiry Ask for A Demo
Pretech SBC RK3566: Versatile Single Board Computer

Pretech SBC RK3566 ODM Industry Applications

The Pretech SBC RK3566 is a versatile engine for ODM projects across diverse industries. It powers smart home hubs, security cameras, and control panels with its robust processing and connectivity. In industrial settings, it acts as the brain for HMI panels and automation controllers, leveraging its I/O and real-time capabilities. The board also drives innovation in digital signage, interactive kiosks, and medical imaging devices, thanks to its 4K video support and NPU for lightweight AI tasks. Its rich interfaces, from multiple displays to Ethernet with PoE, make it a reliable, single-board solution for developing next-generation commercial and industrial smart applications.
Pretech SBC RK3566 ODM Industry Applications

PRODUCT DETAIL

RK3566-E66
  • LPDDR4 2G/3G/4G/6G/8G
    SOC
    LPDDR4 2G/3G/4G/6G/8G
  • Connectivity
    Connectivity
    WiFi4 802.11b/g/n or 802.11a/b/g/n/ac
    Bluetooth 4.2 or 5.0
  • 1 x ADC key <br> 2 x LED + 1 x IR <br> 2 x uart ;1 x uart/RS232 <br> 1 x uart/RS232/RS485 <br> 4 x GPIO ;1 x I2C
    Interface
    1 x ADC key
    2 x LED + 1 x IR
    2 x uart ;1 x uart/RS232
    1 x uart/RS232/RS485
    4 x GPIO ;1 x I2C

What We Do

  • Tooling
    ID Design
    MD Design
  • Software
    Drive Debugging
    System Customization
    Debug Pre-installed applications
  • Hardware
    Schematic Diagrams Design
    PCB Layout
    Specific components design
    Bill of Materials output
    Gerber Files
    RF Design and Verification
    Assembly Drawings
    Test Specifications output
  • Accessories
    Smart Cover
    Docking Charging Station
    Charging Bracket/Dock
    Magnetic BackClip
    Wall Mount
    Stylus Pen
    And more

How We Do

We offer ODM solutions for certain customers who have specific needs which can’t be satisfied by existing devices on the market.
  • 01 Planning
    Market Survey
    Requirements Collection
    Competitiveness Analysis
    Technology Study
    Risk Analysis
    Component Life Cycle Survey
    Cost Evaluation
  • 02 Desgin
    ID Design
    MD Design
    Hardware
    OS
  • 03 Validation
    Trial Samples
    Software Customization
    Performance Tests
    Reliability Tests
    EVT
    DVT
    Certifications
  • 04 Integration
    Assembly Study and SOP
    Pilot Run Production
    Testing Process Study and SOP
    Field Test/Feedbacks
    Improvements
  • 05 Production
    Pilot Run Production
    Mass Production
  • 06 After Service
    Global Warranty
    Extended Warranty Service
    Online Service

Specification

  • OS
    Android
  • SOC
    RK3566, 4 x Cortex-A55, 1.8GHz, 22nm ARM G52 2EE, 0.8 TOPS NPU
  • RAM
    LPDDR4 2G/3G/4G/6G/8G
  • ROM
    EMMC5.1 8GB/16G/32G/64G/128G
  • Media
    4K 60fps H.265/H.264/VP9 decode 1080P 100fps H.265/H.264 codec
  • Display
    MIPI-DSI display port, 4-Lane eDP1.3 display port, FHD
    Dual-LVDS display port,8bit,FHD
    HDMI2.0 Type-A port, (up to 4Kp60 supported)
  • Ethernet
    100M Ethernet port (supports PoE with add-on PoE HAT)
  • Connectivity
    WiFi4 802.11b/g/n or 802.11a/b/g/n/ac, Bluetooth 4.2 or 5.0
  • USB
    USB2.0 x 1 (Type A) OTG
    USB3.0 x 1 (Type A)
    USB2.0 x 4 4Pin-ph2.0
  • TF-Card
    Micro SD card, up to 128GB
  • Audio
    Spearker: 10W x 2 or 3W x 2 stereo Headset: 3.5mm Earphone
    Mic: MIC Input
  • Interface
    1 x ADC key 2 x uart
    1 x uart/RS232/RS485
    1 x I2C
    2 x LED + 1 x IR
    1 x uart/RS232
    4 x GPIO
  • Input Power
    DC5.5mm 12V/2-5A
    Power over Ethernet(requires separate PoE HAT)
  • PCB
    Size: 75 x 142 x 1.6mm
    Process: 6-layers Immersion
    Gold Hole: ∮3.5mm x 4
  • Environment
    Operating temperature -20°C ~ 60°C
