RK3566 SBC Custom Solutions for 21.5”-98” Signage Displays
Model: AIOT
RK3566, 4 x Cortex-A55, 1.8G, 22nm
GPU ARM G52 2EE, 0.8 TOPS NPU
GPU ARM G52 2EE, 0.8 TOPS NPU
AIOT
RK3566, 4 x Cortex-A55, 1.8G, 22nm
GPU ARM G52 2EE, 0.8 TOPS NPU
GPU ARM G52 2EE, 0.8 TOPS NPU
PRODUCT DETAIL
D-AIOT-RCL
-
SOCRK3566, 4 x Cortex-A55, 1.8G, 22nm
GPU ARM G52 2EE, 0.8 TOPS NPU -
ConnectivityWIFI5 802.11a/b/g/n/ac
Bluetooth 5.2,1T1R
Support Mini-PCIE 4G data communication module -
Interface2 X UART (one debug);
1 X Wiegand,
2 X RS232;
2 X RS485.
1 X ADC
1 X PWM
1 X I2C
4 X GPIO
Infrared Remote Control Interface
Specification
-
OSAndroid
-
SOCRK3566, 4 x Cortex-A55, 1.8G, 22nm
GPU ARM G52 2EE, 0.8 TOPS NPU -
RAMLPDDR4 2G/3G/4G/6G/8G
-
ROMEMMC5.1 32G/64GB
-
Media4K 60fps H.265/H.264/VP9 video decoding
1080P 100fps H.265/H.264 video encoding -
DisplayMIPI，4-Lane MIPI-DSI，1920 x 1200@60fps
EDP，4-lane EDP，3000 x 2000@60fps
Dual-LVDS , 1920 x 1080@60fps
HDMI-out，HDMI2.0，1080p@60fps，upto 4K@60fps -
Ethernet1000M Ethernet(supports PoE with add-on PoE HAT)
-
ConnectivityWIFI5 802.11a/b/g/n/ac
Bluetooth 5.2,1T1R
Support Mini-PCIE 4G data communication module -
USB1 TYPE-C USB (OTG),
1 TYPE-A USB3.0,
1 TYPE-A USB2.0,
4 USB2.0 docks -
Micro SD CardMic SD Card Slot x1
-
AudioD class extra large built-in speaker amplifier, support 10W x 2 4R
3.5mm headphone jack output
MIC input -
Interface2 X UART (one debug);
1 X Wiegand,
2 X RS232;
2 X RS485.
1 X ADC
1 X PWM
1 X I2C
4 X GPIO
Infrared Remote Control Interface -
Input PowerInput: AC100-240V.50-60HZ,
Output: DC12V/5.5mm DC head 2A-5A (surge voltage less than 18V, ripple voltage less than 100mV) -
PCBNA
-
EnvironmentOperating temperature -20°C ~ 60°C
