RK3566 SBC Custom Solutions for Raspberry Pi Development and Applications

RK3566, 4 x Cortex-A55, 1.8G, 22nm
GPU ARM G52 2EE, 0.8 TOPS NPU

Inquiry Ask for A Demo

E6

Integrated GPU/VPU/NPU
ARM Mali G522EE, OpenGL ES3.2/2.0/1.1, Vulkan1.1.
VPU support 4K 60 fps H.265 / H.264 /VP9 video decode and 1080P 100fps H.265/H.264 video encode.
NPU 0.8Tops, support (Caffe/Tensor Flow)

PRODUCT DETAIL

SOC

LPDDR4 2G/3G/4G/6G/8G
Connectivity

WIFI5 802.11a/b/g/n/ac
Bluetooth 5.2,1T1R
Interface

40Pin GPIO extension：UART/I2C/SPI/PCM/PWM/ADC/GPIO etc.

Specification

OS

Android/Debian/Buildroot
SOC

RK3566, 4 x Cortex-A55, 1.8GHz, 22nm
GPU ARM G52 2EE, 0.8 TOPS NPU
RAM

LPDDR4 2G/3G/4G/6G/8G
ROM

EMMC5.1 16G/32G/64G
Media

4K 60fps H.265/H.264/VP9 decode
1080P 100fps H.265/H.264 codec
Display

MIPI，2-lane MIPI-DSI, 1920 x 1200@60fps
HDMI-out，HDMI2.0，1080p@60fps，upto 4K@60fps
Camera，4-lane MIPI CSI，Camera interface
Ethernet

1000M Ethernet (supports PoE with add-on PoE HAT)
Connectivity

WIFI5 802.11a/b/g/n/ac
Bluetooth 5.2,1T1R
USB

USB Type C 2.0 (OTG) x 1
USB Type A 3.0 x 1
USB Type A 2.0 x 2
Micro SD Card

Micro SD card,up to 128GB
Audio

Spearker: /
Headset: 3.5mm Earphone
Mic: MIC Input
Interface

40Pin GPIO extension: UART/I2C/SPI/PCM/PWM/ADC/GPIO etc.
Input Power

5V DC via USB-C connector
5V DC via GPIO header
Power over Ethernet (requires separate PoE HAT)
PCB

Size: 56 x 85 x 1.6mm
Process: 6-layers Immersion
Gold Hole: ∮2.5mm x 4
Environment

Operating temperature -20°C ~ 60°C
