RK3566 SOM: Enhancing AI Performance in Compact Devices
Home >> Solution >> SOM

PRODUCT DETAIL

SOM66
project-left
project-left
  • RK3566 SOM: Enhancing AI Performance in Compact Devices LPDDR4 2G/3G/4G/6G/8G
    SOC
    LPDDR4 2G/3G/4G/6G/8G
  • RK3566 SOM: Enhancing AI Performance in Compact Devices WIFI6 802.11a/b/g/n/ac/ax，Bluetooth5.0，2T2R
    Connectivity
    WIFI6 802.11a/b/g/n/ac/ax，Bluetooth5.0，2T2R
  • RK3566 SOM: Enhancing AI Performance in Compact Devices 2 x RS485 for motor control<br>Key interface
    Interface
    2 x RS485 for motor control
    Key interface

  • SPECIFICATION

OS Android
SOC RK3566, 4 x Cortex-A55, 1.8G, 22nm
ARM G52 2EE, 0.8 TOPS NPU
RAM LPDDR4 2G/3G/4G/6G/8G
ROM EMMC5.1 8GB/16G/32G/64G/128G
Media 4K 60fps H.265/H.264/VP9 decode
1080P 100fps H.265/H.264 codec
Display HDMI2.0 port (4Kp60)
4-lane EDP(2560*16000@60FPS)
4-lane MIPI-DSI(1920*1200@60FPS)
Ethernet Gigabit Ethernet interface x 1（The carrier board）
Connectivity WIFI6 802.11a/b/g/n/ac，Bluetooth5.0
USB USB3.0 x 1
USB2.0 x 3(One port with OTG)
TF-Card Micro SD card,up to 128GB（The carrier board）
Audio Can be customized
Interface 4-lane/2x2-lane,Camera ISP,8MP@30fps HDR
UART/SPI/PWM/I2C/ADC/KEY/3.3V etc
Input Power The carrier board can be customized
PCB Size: 45 x 60 x 1.0mm
Process: 6-layer HDI Immersion Gold
Package:LCC134
Environment Operating temperature -20°C ~ 60°C

  • Inquriy
