POE Wall-mount Tablet 10.1inch MT8768 The Ultimate Power-over-Ethernet Tablet Solution
Slim and Stylish Design: Experience the sleek and modern design of our 10.1-inch wall-mount tablet, featuring a slim profile that complements any environment. With its minimalistic look, it's not just a device; it's a statement.
High-Definition Display: Boasting a Full HD 1920x1200 resolution, our POE tablet offers crisp and vivid visuals with its IPS G+FF Full Lamination screen. Enjoy a wide viewing angle and enhanced touch sensitivity with our Anti-Fingerprint (AF) screen technology.
Environmental Sensing: Optional light and temperature/humidity sensors allow for smart adjustments and monitoring, making this POE tablet a versatile tool for various applications.
Sensors: Support for 50CM distance sense wake up, temperature and humidity sensor, and gravity sensor, making it a smart choice for various applications.
NFC Technology: Optional Near Field Communication (NFC) support enables quick and easy data transfer, enhancing the interactivity and functionality of your tablet.
Magnetic Wall Mounting: Innovative magnetic attraction design allows for easy installation on any iron sheet fixed to an 86 box, which can be seamlessly embedded into the wall. This universal mounting solution adapts to various wall box sizes across different countries.
Power Supply: RJ45: Tablet with PoE Power Supply 48V~53V + Ethernet; RJ12: RS485 + Power Supply 12V~24V. Utilize a standard RJ45 network cable for Ethernet access.
USB Type C: For situations where PoE is not available, and only RJ45 carries the network, a Type C + RJ45 interface allows simultaneous use.
Discover the future of Pretech wall-mounted computing with our PoE Wall-mount Tablet 10.1inch. Designed for versatility and efficiency, it's the perfect blend of style and functionality. Elevate your digital experience today with our cutting-edge POE Tablet PC.
Overview
Specifications Inquiry-
10.1" FHD 1920 x 1200 G+FF -
MT8768 4 x Arm Cortex-A53, 2.0 GHz +4 x Arm Cortex-A53, 1.5 GHz -
Android 14 Google GMS -
RAM:4GB
ROM:64GB -
Option -
WIFI ac a/b/g/n, BT5.0, -
Support 50CM distance sense wake up;
Temperature and humidity sensor;
Gravity sensor; -
NA
Specifications
Inquiry-
CPUMT8768 4 x Arm Cortex-A53, 2.0 GHz +4 x Arm Cortex-A53, 1.5 GHz
-
OSAndroid 14 Google GMSA
-
Screen10.1" FHD 1920 x 1200 G+FF
-
RAM4GB
-
Storage64GB
-
Wi-Fi/BluetoothWIFI ac a/b/g/n, BT5.0,
-
LTE-FDDNA
-
LTE-TDDNA
-
3GNA
-
2GNA
-
CameraOption
-
SupportSupport 50CM distance sense wake up;
Temperature and humidity sensor;
Gravity sensor; -
I/ORJ45: PoE Power Supply 48V~53V + Ethernet;
RJ12: RS485 + Power Supply 12V~24V; (With a standard RJ45 network cable, you can also access the Ethernet network)
USB TYPE C: (If there is no PoE, and only RJ45 carries the network, you can use a TYPE C + RJ45 interface to use simultaneously); -
BatteryNA
-
Dimensions243 x 152 x 10mm
-
Weight548g
-
Speakerdual speakers
-
LTENA
Inquiry
FAQs
- Unique Mounting & Design
- Sensing & Interactivity Features
- Power and Connectivity Redundancy
-
What unique mounting solution does the WP101 offer, and what is its primary advantage?The WP101 features an innovative Magnetic Wall Mounting design, allowing it to be easily installed on any iron sheet fixed to a standard 86-type wall box. This design provides a seamless, embedded look, simplifies installation, and offers a universal solution compatible with common wall box sizes across different countries, enhancing its aesthetic appeal (Slim and Stylish Design).
-
How does the display technology support high-quality interaction and maintenance?The tablet uses a 10.1-inch Full HD 1920x1200 IPS G+FF Full Lamination screen with Anti-Fingerprint (AF) technology. This combination ensures crisp, vivid visuals, enhanced touch sensitivity, and reduces visual clutter from smudges, making it ideal for high-traffic, interactive HMI or digital signage applications where clarity and hygiene are important (High-Definition Display).
-
What type of environmental and proximity sensing capabilities are optional for the WP101?The WP101 supports various smart sensors, including distance sense wake-up (50CM), temperature and humidity sensor, and a gravity sensor. These features enable intelligent operations, such as automatically waking up the screen when a person approaches, or adjusting system behavior based on ambient conditions, making it highly versatile for smart automation (Environmental Sensing).
-
Can the WP101 be used for identity verification or quick data transfer tasks?Yes, the WP101 supports Optional Near Field Communication (NFC) Technology. This allows for quick and easy data transfer or interaction, making it suitable for applications requiring badge scanning for access control, staff authentication in enterprise solutions, or contactless payment integration in specific POS solutions (NFC Technology).
-
The WP101 primarily uses PoE. What provisions are made for power if PoE is not available or if RS485 is needed?The tablet provides multiple power/data input options. It supports standard PoE (48V~53V)via the RJ45 port. Additionally, it features anRJ12 portfor RS485 + 12V~24V Power Supply. This redundancy allows the tablet to be deployed flexibly, either via PoE for simpler installation or via industrial power/RS485 for enhanced control system integration (Power Supply).
-
In a scenario where the RJ45 port is used only for the network without PoE power, how can the tablet be powered?The WP101 has a clever design feature that allows simultaneous use of a USB Type C interface and the RJ45 network connection. If the network cable in the RJ45 port does not carry PoE power, the Type-C port can be used to provide the necessary power supply, ensuring continuous network operation (USB Type C).
