S626 Custom Security Phone with Dual USB C Port - ODM Smartphone

MODEL: S626

ODM Security Phone: Advanced Privacy Protection with Dual SIM, Dual Type-C Ports, and Robust Security Features

Powerful Performance: MTK8788 octa-core CPU for fast and responsive performance.

Display: 6.26" HD+ 720 x 1520 IPS display with 5-point touch for clear and responsive visuals.

Dual SIM, eSIM & Physical SIM Support: Flexibly manage multiple networks with support for both eSIM and physical SIM cards.

Dual Type-C Ports: Two Type-C ports for PD charging and high-speed data transfer.

Advanced Sensors:

Fingerprint sensor for secure access.

Custom SOS button for emergency situations.

Compass and gyroscope for enhanced navigation.

Inquiry Ask for A Demo

Applications:

Overview

Specifications Inquiry

6.26inch HD 720*1520 IPS, G+FF
MTK8788V/WA 4*Cortex A73 2.3GHz+4*Cortex A53 1.8GHz
Android
RAM 2/3/4/6GB Storage 32/64/128GB
Front 16MP+0.3MP, Rear 8MP
802.11 a/b/g/n ac 5GHz, BT5.0
Gravity sensor, Ambinent light sensor, Proximity sensor, Compass, Gyroscope, Fingerprint, nano SIM*1+built-in E-SIM*1
4.4V/3400mAh Li-polymer

Specification

Overview

Specifications

Inquiry

CPU

MTK8788V/WA 4*Cortex A73 2.3GHz+4*Cortex A53 1.8GHz
OS

Android
Screen

6.26 inch HD 720*1520 IPS, G+FF
RAM

2/3/4/6GB
Storage

32/64/128GB
Wi-Fi/Bluetooth

802.11 a/b/g/n ac 5GHz, BT5.0
3G

B1 (2100MHz)
2G

900MHz, 1800MHz
Camera

Front 16MP+0.3MP, Rear 8MP
Support

Gravity sensor, Ambinent light sensor, Proximity sensor, Compass, Gyroscope, Fingerprint, nano SIM*1+built-in E-SIM*1
Battery

4.4V/3400mAh Li-polymer
Dimensions

159.7*77.7*9.5mm
Weight

213g
LTE

4G ：B3(1800MHz), B7(2600MHz), B20(800MHz), B28(700MHz)

Inquiry

Overview Specifications

Key Security & Hardware Features

What makes the Pretech S626 an "ODM Security Phone"?

The S626 is designed as a customizable, secure platform for enterprise and specialized use. Its core security features include:
1）Secure Access: Integrated Fingerprint Sensor for reliable authentication.
2）Emergency Feature: A Customizable SOS Button for immediate, mission-critical response in corporate or field environments.
3）Privacy: Built on an Android platform that Pretech can tailor for enhanced privacy protection and locked-down security protocols (see customization below).
How does the Dual Type-C Port feature benefit professional users?

The Dual Type-C Ports offer unparalleled utility for enterprise deployment:
1）Simultaneous Operations: Allows for PD Charging (fast power delivery) while simultaneously connecting to high-speed peripherals or data transfer devices.
2）Fixed Operations: Ideal for use in specific POS or fixed scanning stations where charging and peripheral connectivity are non-negotiable.
Does the S626 support flexible cellular connectivity?

Yes. The S626 provides maximum flexibility with support for both a physical Nano SIM card and a Built-in E-SIM capability. This is perfect for users who need to manage separate corporate and personal numbers, or for deployment where local network provisioning is required (GEO advantage).

Customization & Enterprise Deployment

Can Pretech customize the S626's software and OS for my organization?

Absolutely. As your dedicated ODM partner, Pretech offers deep software customization for the Android OS, including:
1）Custom Firmware:Implementing proprietary security stacks, remote management features, and device locking/kiosk modes.
2）Pre-loaded Apps:Integrating your essential enterprise applications directly into the firmware for immediate fleet deployment.
3）Branding:Custom boot logos, splash screens, and a tailored user interface (UI) to match your corporate identity.
Can the physical features, like the SOS button or cameras, be customized?

Yes. The Custom SOS Button can be programmed to trigger specific actions (e.g., instant reporting, emergency communication). Furthermore, we can customize camera modules (Front 16MP + 0.3MP, Rear 8MP) to meet unique quality or specialized image capture needs (e.g., barcode scanning optimization).
What customization is available for the S626's performance specifications?

We offer flexible hardware configurations to match budget and performance requirements:
1）Processor: Utilizing the capable MTK8788V/WA Octa-core CPU.
2）Memory & Storage: Configurable options for RAM (2/3/4/6GB) and Storage (32/64/128GB).
3）Battery: While the standard is 3400mAh, we can explore custom power solutions for extreme-use cases based on project volume.

Global Connectivity & Certifications (GEO/SEO Focus)

What network bands does the S626 support globally?

The S626 is engineered for global enterprise use, supporting a wide range of cellular bands, including key 4G LTE frequencies such as B3 (1800MHz), B7 (2600MHz), B20 (800MHz), and B28 (700MHz), ensuring reliable data and voice communication across major markets in Europe, North America, and emerging regions.
Is the S626 suitable for industries requiring robust positioning and navigation?

Yes. The S626 features advanced sensors like Compass and Gyroscope, alongside standard GPS capabilities, making it highly suitable for applications requiring precise location tracking and directional data, such as field logistics, asset management, and specialized mapping services.
Can Pretech ensure the S626 meets regional compliance standards (e.g., FCC, CE)?

We proactively support global compliance. We can manage and provide necessary certifications such as CE, FCC, and RoHS on an OEM/ODM basis, guaranteeing that your custom-branded S626 devices are fully compliant and ready for deployment in your target country or region.
